MULTITECH©
SocketModem ®Cell LTE
MTSMC-Lxx Device Guide
SOCKETMODEM® CELL LTE DEVELOPER GUIDE
2 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
SocketModem®Cell LTE Developer Guide
Models: MTSMC-LEU1, MTSMC-LEU1-U, MTSMC-LAT1, MTSMC-LAT1-U, MTSMC-LVW2, MTSMC-LVW2-U
Part Number: S000614, Version 1.10
Copyright
This publication may not be reproduced, in whole or in part, without the specific and express prior written permission signed by an executive officer of
Multi-Tech Systems, Inc. All rights reserved. Copyright © 2018 by Multi-Tech Systems, Inc.
Multi-Tech Systems, Inc. makes no representations or warranties, whether express, implied or by estoppels, with respect to the content, information,
material and recommendations herein and specifically disclaims any implied warranties of merchantability, fitness for any particular purpose and non-
infringement.
Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of
Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.
Trademarks and Registered Trademarks
Multi-Tech, and the Multi-Tech logo, and SocketModem are trademarks and registered trademarks of Multi-Tech Systems, Inc. All other products and
technologies are the trademarks or registered trademarks of their respective holders.
Legal Notices
The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with
applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or
death, significant property damage, or serious physical or environmental damage. Examples of such use include life support machines or other life
preserving medical devices or systems, air traffic control or aircraft navigation or communications systems, control equipment for nuclear facilities, or
missile, nuclear, biological or chemical weapons or other military applications (“Restricted Applications”). Use of the products in such Restricted
Applications is at the user’s sole risk and liability.
MULTITECH DOES NOT WARRANT THAT THE TRANSMISSION OF DATA BY A PRODUCT OVER A CELLULAR COMMUNICATIONS NETWORK WILL BE
UNINTERRUPTED, TIMELY, SECURE OR ERROR FREE, NOR DOES MULTITECH WARRANT ANY CONNECTION OR ACCESSIBILITY TO ANY CELLULAR
COMMUNICATIONS NETWORK. MULTITECH WILL HAVE NO LIABILITY FOR ANY LOSSES, DAMAGES, OBLIGATIONS, PENALTIES, DEFICIENCIES, LIABILITIES,
COSTS OR EXPENSES (INCLUDING WITHOUT LIMITATION REASONABLE ATTORNEYS FEES) RELATED TO TEMPORARY INABILITY TO ACCESS A CELLULAR
COMMUNICATIONS NETWORK USING THE PRODUCTS.
The MultiTech products and the final application of the MultiTech products should be thoroughly tested to ensure the functionality of the MultiTech
products as used in the final application. The designer, manufacturer and reseller has the sole responsibility of ensuring that any end user product into
which the MultiTech product is integrated operates as intended and meets its requirements or the requirements of its direct or indirect customers.
MultiTech has no responsibility whatsoever for the integration, configuration, testing, validation, verification, installation, upgrade, support or maintenance
of such end user product, or for any liabilities, damages, costs or expenses associated therewith, except to the extent agreed upon in a signed written
document. To the extent MultiTech provides any comments or suggested changes related to the application of its products, such comments or suggested
changes is performed only as a courtesy and without any representation or warranty whatsoever.
Contacting MultiTech
Knowledge Base
The Knowledge Base provides immediate access to support information and resolutions for all MultiTech products. Visit http://www.multitech.com/kb.go.
Support Portal
To create an account and submit a support case directly to our technical support team, visit: https://support.multitech.com.
Support
Business Hours: M-F, 8am to 5pm CT
Country By Email By Phone
Europe, Middle East, Africa: support@multitech.co.uk +(44) 118 959 7774
U.S., Canada, all others: support@multitech.com (800) 972-2439 or (763) 717-5863
Warranty
To read the warranty statement for your product, visit www.multitech.com/warranty.go. For other warranty options, visit www.multitech.com/es.go.
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive, Mounds View, MN 55112
Phone: (800) 328-9717 or (763) 785-3500
Fax (763) 785-9874
CONTENTS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 3
Contents
Chapter 1 – Product Overview ................................................................................................................................. 6
Product Overview.......................................................................................................................................................... 6
Documentation ............................................................................................................................................................. 6
Product Build Options ................................................................................................................................................... 7
Chapter 2 – Mechanical Drawings............................................................................................................................ 8
MTSMC-Lxxx.................................................................................................................................................................. 8
MTSMC-Lxxx-U .............................................................................................................................................................. 9
Chapter 3 – Specifications...................................................................................................................................... 10
MTSMC-LAT1 and MTSMC-LAT1-U Specifications ...................................................................................................... 10
MTSMC-LVW2 and MTSMC-LVW2-U Specifications................................................................................................... 11
MTSMC-LEU1 and MTSMC-LEU1-U Specifications...................................................................................................... 12
Frequency Bands (LEU1) ............................................................................................................................................. 13
LE910 Telit Transmission Output Power..................................................................................................................... 14
Underwriters Laboratories, Inc. Required Global Positioning System (GPS) Statement ........................................... 14
Powering Down Your Device ...................................................................................................................................... 14
UART DC Electrical Characteristics.............................................................................................................................. 15
Absolute Maximum Rating........................................................................................................................................ 15
Electrical Characteristics Other Pins ........................................................................................................................... 15
Pinout Specifications................................................................................................................................................... 16
Pin Availability by Build............................................................................................................................................... 16
Power Measurements................................................................................................................................................. 18
MTSMC-LAT1 Power Draw........................................................................................................................................ 18
MTSMC-LAT1-U Power Draw .................................................................................................................................... 18
MTSMC-LVW2 Power Draw ...................................................................................................................................... 19
MTSMC-LVW2-U Power Draw .................................................................................................................................. 19
MTSMC-LEU1 Power Draw........................................................................................................................................ 19
MTSMC-LEU1-U Power Draw.................................................................................................................................... 20
Mounting Hardware.................................................................................................................................................... 20
Recommended Parts................................................................................................................................................. 20
Chapter 4 – Antennas ............................................................................................................................................ 21
Antenna System Cellular Devices................................................................................................................................ 21
Requirements for Cellular Antennas with regard to FCC/IC Compliance ................................................................. 21
PTCRB Requirements .................................................................................................................................................. 21
Antenna Overview ...................................................................................................................................................... 21
EAD Antenna ............................................................................................................................................................ 21
Wieson Antenna........................................................................................................................................................ 22
LTE Antenna Diversity ................................................................................................................................................. 23
CONTENTS
4 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Selecting Antennas ................................................................................................................................................... 23
Placing External Antennas ........................................................................................................................................ 23
Placing GPS Antennas .............................................................................................................................................. 23
Antenna Approvals and Safety Considerations ........................................................................................................ 23
Diversity and Power Draw ....................................................................................................................................... 24
GPS Antenna Specifications ........................................................................................................................................ 24
MultiTech Ordering Information............................................................................................................................... 24
Antenna Specifications.............................................................................................................................................. 24
OEM Integration ......................................................................................................................................................... 24
FCC & IC Information to Consumers ......................................................................................................................... 24
FCC Grant Notes........................................................................................................................................................ 25
Host Labeling............................................................................................................................................................. 25
Chapter 5 – Safety Information .............................................................................................................................. 26
Handling Precautions .................................................................................................................................................. 26
Power Supply Caution................................................................................................................................................. 26
Radio Frequency (RF) Safety ....................................................................................................................................... 26
Sécurité relative aux appareils à radiofréquence (RF).............................................................................................. 26
Interference with Pacemakers and Other Medical Devices ...................................................................................... 27
Potential interference............................................................................................................................................... 27
Precautions for pacemaker wearers ........................................................................................................................ 27
Vehicle Safety.............................................................................................................................................................. 27
Device Maintenance ................................................................................................................................................... 28
Notice regarding Compliance with FCC, EU, and Industry Canada Requirements for RF Exposure........................... 28
User Responsibility...................................................................................................................................................... 28
Chapter 6 – Regulatory Information....................................................................................................................... 29
EMC, Safety, and Radio Equipment Directive (RED) Compliance .............................................................................. 29
47 CFR Part 15 Regulation Class B Devices ................................................................................................................. 29
Industry Canada Class B Notice................................................................................................................................... 29
FCC Grant Information ................................................................................................................................................ 30
MTSMC-LAT1 and MTSMC-LAT1-U ........................................................................................................................... 30
MTSMC-LVW2 and MTSMC-LVW2-U........................................................................................................................ 32
Industry Canada Certification ..................................................................................................................................... 32
MTSMC-LAT1 and MTSMC-LAT1-U ........................................................................................................................... 33
MTSMC-LVW2 and MTSMC-LVW2-U........................................................................................................................ 35
Chapter 7 – Environmental Notices........................................................................................................................ 37
Waste Electrical and Electronic Equipment Statement .............................................................................................. 37
WEEE Directive.......................................................................................................................................................... 37
Instructions for Disposal of WEEE by Users in the European Union ........................................................................ 37
REACH Statement ....................................................................................................................................................... 37
Registration of Substances........................................................................................................................................ 37
Substances of Very High Concern (SVHC) ................................................................................................................ 37
CONTENTS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 5
Restriction of the Use of Hazardous Substances (RoHS) ............................................................................................ 38
Information on HS/TS Substances According to Chinese Standards ......................................................................... 39
Information on HS/TS Substances According to Chinese Standards (in Chinese) ...................................................... 40
Chapter 8 – Labels.................................................................................................................................................. 41
Approvals and Certifications....................................................................................................................................... 41
Example Labels............................................................................................................................................................ 41
Chapter 9 – Using Connection Manager ................................................................................................................. 43
Installing Connection Manager and Connecting a Device .......................................................................................... 43
Setting Up a Serial Device ........................................................................................................................................... 44
Troubleshooting.......................................................................................................................................................... 46
Serial COM port is not available in the Serial Modem Settings................................................................................ 46
Device is not detected ("No Device") ....................................................................................................................... 46
MultiConnect Cell USB Modem is not detected ....................................................................................................... 47
Index...................................................................................................................................................................... 48
PRODUCT OVERVIEW
6 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Chapter 1 – Product Overview
Product Overview
SocketModem Cell models are complete, ready-to-integrate communications devices that offer standards-based
LTE performance. These quick-to-market communications devices allow developers to add wireless communication
to products with a minimum of development time and expense. SocketModem Cell models are based on industry-
standard open interfaces and use MultiTech’s Universal Socket design.
Documentation
The following documentation is available at multitech.com/support.
Document Description Part Number
SocketModem Cell LTE
Device Guide
This document. Provides overview, safety and regulatory
information, design considerations, schematics, and device
information.
S000614
Universal Developer Kit 2.0
Developer Guide
Information for developing with the MTUDK2 Developer Kit.
Includes an overview, design considerations, schematics, and
installation and operation information.
S000610
Universal Socket Developer
Guide
Information for developing with the MTSMI-UDK Developer
Kit. Includes an overview, design considerations, schematics,
and installation and operation information.
S000342
USB Driver Installation Guide Instructions for installing USB drivers on Linux and Windows
Systems.
S000616
Getting Started with AT
Commands for LEU1 Devices
AT Command release notes and basic operations for MTSMC-
LEU1 and MTSMC-LEU1-U Devices.
S000615
Getting Started with AT
Commands for LAT1 Devices
AT Command release notes and basic operations for MTSMC-
LAT1 and MTSMC-LAT1-U Devices.
S000617
Telit LE910 AT Commands
Reference Guide
For LAT1 and LEU1. Lists AT Commands and parameters used
to configure your device, used with firmware version
17.00.5x3
80421ST10585A
Rev 3
Getting Started with AT
Commands for LVW2 Devices
AT Command release notes and basic operations for MTSMC-
LVW2 and MTSMC-LVW2-U Devices.
S000618 (pending)
Telit LE 910 AT Commands
Reference Guide
For LVW2 . Lists AT Commands and parameters used to
configure your device, used with firmware version 17.01.571
80407ST10116a
Rev 12
PRODUCT OVERVIEW
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 7
Product Build Options
Product Description Carrier/Region
MTSMC-LVW2 4G LTE embedded cellular modem with GPS/GLONASS
(Serial Interface)
Verizon
MTSMC-LVW2-U 4G LTE embedded cellular modem with GPS/GLONASS
(USB Interface)
Verizon
MTSMC-LEU1 (RED
Compliant)
4G LTE with HSPA+ fallback embedded cellular modem
with GPS/GLONASS (Serial Interface)
Europe/Australia
MTSMC-LEU1-U (RED
Compliant)
4G LTE with HSPA+ fallback embedded cellular modem
with GPS/GLONASS (USB Interface)
Europe/Australia
MTSMC-LAT1 4G LTE with HSPA+ fallback embedded cellular modem
with GPS/GLONASS (Serial Interface)
AT&T/North America
MTSMC-LAT1-U 4G LTE with HSPA+ fallback embedded cellular modem
with GPS/GLONASS (USB Interface)
AT&T/North America
Developer Kits
Use either of the following developer kits with MTSMC devices.
MTUDK2-ST-Cell Developer Kit for SocketModem, and Dragonfly cellular
devices.
All
MTSMI-UDK Developer Kit for cellular, analog, BlueTooth, and WiFi
SocketModems.
All
Note:
These units ship without network activation.
To connect them to the cellular network, you need a cellular account. For more information, refer to
Account Activation.
The complete product code may end in .Rx. For example, MTSMC-LAT1.Rx, where R is revision and x
is the revision number.
All builds can be ordered individually or in 50-packs. Add SP to the model number for a single pack.
H v; M7[1135]
8 3 MIN Fonst 105[2 as]
g _: REMOVAL
3: u, 74000015]
:3, 5! sm[1s]—— sum a:
am ‘ '
ssnhs] ‘
susmus] - '
s75[2477] ‘
- E
'55
o
g muss]
. MAX comp. —- ~—
: HEIGHTTOF
3
a :3“? a) 12:3[325] NPTHCD
w 7v -—-—
gag SE «26mm
:3: :33 W COMP - "-
:1 3: E :3 HEIGHT BOTTOM
I l a a _
11n[2.79] :- OCI_' 9 [1 V 7
" .020[0 51]
Elm] In - I mums
Lsusm‘fl ° 505(1537] —@ ° §sz°§§§§§
mm .1 n - 739[1s.76] 71H =‘
«ween E 0 mm 76] a T‘
n
i D
6"?” 2- mm; 2mm 75] f 247152 75] z
, -.-4 =
$3323: 235mm 2529M 7s] =
mm - 2
Lemma "P a rawm 22] :
WW" - I 31so[3u 01] =
MTSMC-LVWZ _ 25:5[643] :n15"
MTSMC-LVW3 gzéiuéfisg) g Pm LENGTH
MTSMC-LEU1 ‘ .2 062[1.57] gums"
MTSMC-LAT1 ”PM” 50170” g PCETHICKNESS " ‘—
MTSMC‘LAT‘ NOTES: DIMENSIONS IN In [mm]
MECHANICAL DRAWINGS
8 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Chapter 2 – Mechanical Drawings
MTSMC-Lxxx
3' g «7W as]
o 0
fig 2 Tom]
53 g 4nn[1n 15]
o o «I —
| l 591[15]~ SW‘Q
ow] , f
630m] -
505m 45] - '“
97mm] 7 I}
- ° E
5E
a Iw[3 56]
MAX comp —- «—
us -a 1,- HEIGHT TOF'
’®° 33.; at 12H: 25] NPTH (3)
3 E 3
%% Wééfifip
E§E HEIGHT BoTToM
I J ‘ ‘— o u
.110[2.79] SWQ [ ] v.7
o _
DIP], m - . £5222
mm mm 37] —fl ° :OEEEO S125: 352"
(“END a: V739[13.76] 71H ~
mm av ,596[22.76] if =
m, Lzuwz ss . 1,132[2a.76] ‘
ID' - -
I _ -
n I U7B[2]
U I: : TVP
mm“ -. . .' $339315“, 2,471[52.7s] 2471[62.76] :
.. 3: W W I :
.. . za usaranI/UI , . a =
mm ......., F 3 040W 22]
(Ia-— 3150mm] 3-4'
MTSMC-LVWZ-U fl 253[s 43] z 015"
MTSMc-LVWZHJ $35333 93 PIN LENGTH
MTSMC-LEU1-U E. 062 157 30075"
MTSMC-LAT1-U 7°“ AND 50770” e PClg THIl‘KNESS ‘—
MTSMC'LATW NOTES: DIMENSIONS IN In [mm]
MECHANICAL DRAWINGS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 9
MTSMC-Lxxx-U
SPECIFICATIONS
10 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Chapter 3 – Specifications
MTSMC-LAT1 and MTSMC-LAT1-U Specifications
Category Description
General
Standards LTE 3GPP Release 9
HSPA+ 21/GPRS fallback
USB Interface is CDC-ACM compliant
TCP/IP Functions FTP, SMTP, SSL, TCP, UDP
Frequency Bands 4G: 700 (B17)/850 (B5)/AWS 1700 (B4)/1900 (B2)
3G: 850 (B5)/1900 (B2)
2G: 850/1900
Speed
Data Speed LTE: 100 Mbps downlink/50 Mbps uplink
HSPA+: 21 Mbps downlink/5.76 Mbps uplink
Interface
USB Interface USB 2.0 high speed 480 Mbps
Serial Modem Interface Up to 921.6 Kbps
Physical Description
Weight 0.4 oz. (10 g)
Dimensions Refer to Mechanical Drawing for Dimensions.
Connectors
Antenna Connector 3 surface mount UFL connectors for cellular, Rx diversity/MIMO, and GPS
SIM 1.8V and 3V SIM holder for mini-SIM card
Environment
Operating Temperature -40° C to +85° C
Storage Temperature -40° C to +85° C
Humidity 20%-90% RH, non-condensing
Power Requirements
Input Voltage 3.3 - 5 VDC
SPECIFICATIONS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 11
Category Description
SMS
SMS Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
Certifications and Compliance
EMC Compliance FCC Part 15 Class B
Radio Compliance FCC Part 22, 24, 27
Safety Compliance UL 60950-1 2nd ED
cUL 60950-1 2nd ED
IEC 60950-1 2nd ED
Network Compliance PTCRB
Carrier AT&T
MTSMC-LVW2 and MTSMC-LVW2-U Specifications
Category Description
General
Standards LTE 3GPP Release 9
USB Interface is CDC-ACM compliant
TCP/IP Functions FTP, SMTP, SSL, TCP, UDP
Frequency Bands 4G: 700 (B13) / AWS 1700 (B4)
Speed
Data Speed LTE: 100 Mbps downlink/50 Mbps uplink
Interface
USB Interface USB 2.0 high speed compatible
UART Interface 0-1.8V
Physical Description
Weight 0.4 oz. (10 g)
Dimensions Refer to Mechanical Drawing for Dimensions.
Connectors
Antenna Connector 3 surface mount UFL connectors for cellular, Rx diversity/MIMO, and GPS
SIM 1.8V and 3V SIM holder for mini-SIM card
Environment
Operating Temperature -40° C to +85° C
SPECIFICATIONS
12 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Category Description
Storage Temperature -40° C to +85° C
Humidity 20%-90% RH, non-condensing
Power Requirements
Input Voltage 3.3-5 VDC
SMS
SMS Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
Certifications and Compliance
EMC Compliance FCC Part 15 Class B
Radio Compliance FCC Part 27
Safety Compliance UL 60950-1 2nd ED
cUL 60950-1 2nd ED
IEC 60950-1 2nd ED
Carrier Verizon
MTSMC-LEU1 and MTSMC-LEU1-U Specifications
Category Description
General
Standards LTE 3GPP Release 9
HSPA+ 21/GPRS fallback
USB Interface is CDC-ACM compliant
TCP/IP Functions FTP, SMTP, SSL, TCP, UDP
Frequency Bands Refer to the following Frequency Bands table for details.
Speed
Data Speed LTE: 100 Mbps downlink/50 Mbps uplink
HSPA+: 42 Mbps downlink/5.76 Mbps uplink
Interface
USB Interface USB 2.0 high speed compatible
UART Interface 0-1.8V
Physical Description
Weight 0.4 oz. (10 g)
Dimensions Refer to Mechanical Drawing for Dimensions.
SPECIFICATIONS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 13
Category Description
Connectors
Antenna Connector 3 surface mount UFL connectors for cellular, Rx diversity/MIMO, and GPS
SIM 1.8V and 3V SIM holder for mini-SIM card
Environment
Operating Temperature -40° C to +85° C
Storage Temperature -40° C to +85° C
Humidity 20%-90% RH, non-condensing
Power Requirements
Input Voltage 3.3-5 VDC
SMS
SMS Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
Certifications and Compliance
EMC Compliance EN55022 Class B, EN55024
Radio Compliance EN 301 511, EN 301 489-1, EN 301 489-52, CE RED Radio/SAR
Safety Compliance IEC 60950-1 2nd ED
AS/NZS 60950.1
Frequency Bands (LEU1)
Mode Freq. TX (MHz) Freq. RX (MHz) Channels TX - RX offset
EGSM900 890 - 915 935 - 960 0 - 124 45 MHz
880 - 890 925 - 935 975 - 1023 45 MHz
DCS1800 1710 - 1785 1805 - 1880 512 - 885 95MHz
WCDMA850 (band V) 824 - 849 869 - 894 Tx: 4132 - 4233
Rx: 4357 - 4458
45MHz
WCDMA900 (band
VIII)
880 - 915 925 - 960 Tx: 2712 - 2863
Rx: 2937 - 3088
45MHz
WCDMA2100 (band
I)
1920 - 1980 2110 - 2170 Tx: 9612 - 9888
Rx: 10562 -
10838
190MHz
SPECIFICATIONS
14 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Mode Freq. TX (MHz) Freq. RX (MHz) Channels TX - RX offset
LTE800 (band XX) 832 - 862 791 - 821 Tx: 24150 -
24449
Rx: 6150 - 6449
-41MHz
LTE1800 (band III) 1710 - 1785 1805 - 1880 Tx: 19200 -
19949
Rx: 1200 - 1949
95MHz
LTE2600 (band VII) 2500 - 2570 2620 - 2690 Tx: 20750 -
21449
Rx: 2750 - 3449
120MHz
LE910 Telit Transmission Output Power
Band Power Class
GSM 850/900 MHz 4 (2W)
DCS 1800, PCS 1900 MHz 1 (1W)
EDGE, 850/900 MHz E2 (0.5W)
EDGE, 1800/1900 MHz Class E2 (0.4W)
WCDMA/FDD 800/850/900, 1900/2100 MHz Class 3 (0.25W)
LTE FDD 700/800/850/900, 1800/1900/2100/2600
MHz
Class 3 (0.2W)
Underwriters Laboratories, Inc. Required Global Positioning System
(GPS) Statement
Note the following information required by Underwriters Laboratories: Underwriters Laboratories, Inc.
Underwriters Laboratories Inc.(“UL”) has not tested the performance or reliability of the Global Positioning System
(“GPS”) hardware, operating software or other aspects of this product. UL has only tested for fire, shock or
casualties as outlined in UL’s Standard(s) for Safety. UL60950-1 Certification does not cover the performance or
reliability of the GPS hardware and GPS operating software. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS RELATED FUNCTIONS
OF THIS PRODUCT.
Powering Down Your Device
CAUTION: Failing to properly power down the device before removing power may corrupt your device's file
system.
To properly power down your device, use the following sequence :
1. Issue the AT#SHDN command.
SPECIFICATIONS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 15
2. Wait 30 seconds.
3. Power off or disconnect power.
Note: If you send AT#SHDN and do not remove power, the radio restarts after 60 seconds.
UART DC Electrical Characteristics
Units: Volts
Applies to the following pins:
Pin Signal Name Pin Signal Name
J33 -RTS J37 -DSR
J34 -RXD J38 -CTS
J35 -TXD J39 -DCD
J36 -RI J40 -DTR
Parameter Minimum Maximum
3.3 Volt Powered
Input Low Level 0 0.55
Input High Level 1.5 3.3
Output Low Level 0 0.55
Output High Level 2.35 3.3
5 Volt Powered
Input Low Level 0 0.8
Input High Level 2.3 5
Output Low Level 0 0.55
Output High Level 3.7 5
Absolute Maximum Rating
All models can run with an input voltage of either 3.3V or 5V. The maximum voltage on any signal pin equals the
input voltage.
Electrical Characteristics Other Pins
Pin Signal
Name
VIL Min VIL Max VIH Min VIH Max VOL Min VOL Max VOH Min VOH Max
J24 -RESET -- 0.8 2.0 -- -- -- -- --
J25 USB VBUS -0.3 0.8 2.0 8.7 -- -- -- --
J26 GND -- -- -- -- -- -- -- --
J27 USB DP -- 0.8 2 -- -- 0.3 2.8 --
SPECIFICATIONS
16 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Pin Signal
Name
VIL Min VIL Max VIH Min VIH Max VOL Min VOL Max VOH Min VOH Max
J28 USB DN -- 0.8 2 -- -- 0.3 2.8 --
J41 GND -- -- -- -- -- -- -- --
J58 -LED LINK -- -- -- -- 0 0.45 2.85 3.3
J61 VCC -- -- -- -- -- -- -- --
J63 GND -- -- -- -- -- -- -- --
Pinout Specifications
Pin Signal Name Logic Level Voltage1In/Out Description
J24 –RESET 3.3 – 5.0 I Device reset (active low)
J25 USB VBUS 3.3 – 5.0 I USB power supply input
J26 GND GND GND Ground
J27 USB DP 3.3 I/O USB data
J28 USB DN 3.3 I/O USB data
J33 –RTS 5.0 I Request to send (active low)
J34 –RXD 5.0 O Received data (active low)
J35 –TXD 5.0 I Transmitted data (active low)
J36 –RI 5.0 O Ring indicator (active low)
J37 –DSR 5.0 O Data set ready (active low)
J38 –CTS 5.0 O Clear to send (active low)
J39 –DCD 5.0 O Data carrier detect (active low)
J40 –DTR 5.0 I Data terminal ready (active low)
J41 GND GND GND Ground
J58 –LED LINK 3.3 O Link status (active low, can sink up to
150mA)
J61 VCC 5.0 PWR DC input power
J63 GND GND GND Ground
1A hyphen (-) indicates a range of acceptable logic levels.
Pin Availability by Build
Pin Signal Name Serial Only USB Only
J24 –RESET X X
J25 USB VBUS X
J26 GND X X
SPECIFICATIONS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 17
Pin Signal Name Serial Only USB Only
J27 USB DP X
J28 USB DN X
J33 –RTS X
J34 –RXD X
J35 –TXD X
J36 –RI X
J37 –DSR X
J38 –CTS X
J39 –DCD X
J40 –DTR X
J41 GND X X
J58 –LED LINK X
J61 VCC X X
J63 GND X X
SPECIFICATIONS
18 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Power Measurements
Multi-Tech Systems, Inc. recommends that you incorporate a 10% buffer into your power source when determining
product load.
Note:
The following notes apply to the following tables.
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what transmission
scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
Inrush Charge: The input current during power up, or a reset.
MTSMC-LAT1 Power Draw
Radio Protocol Sleep Mode w/
Connection to Live
Network (Active SIM
Installed) (Amps)
Sleep Mode Current
(Amps)
Cellular Connection
Idle (No Data) (Amps)
(AVG) Measured
Current (Amps) at Max
Power
3.3 Volts
WCDMA 0.0049 0.021 0.026 0.558
LTE 0.027 0.033 0.034 0.401
5 Volts
WCDMA 0.012 0.012 0.018 0.556
LTE 0.013 0.020 0.019 0.4000
MTSMC-LAT1-U Power Draw
Radio
Protocol
Sleep Mode
Current
(Amps)
Cellular
Connection Idle
(No Data)
(Amps)
(AVG) Measured
Current (Amps) at
Max Power
TX Pulse (AVG)
Amplitude Current
(Amps) for GSM850 or
Peak Current for
HSDPA/LTE )
Total Inrush
Charge Measured
in Millicoulomb
(mC)
3.3 Volts
GPRS N/A 0.056 0.750 3.48 2.65
LTE N/A 0.048 0.909 N/A N/A
5 Volts
GPRS N/A 0.032 0.293 2 3.64
LTE N/A 0.029 0.560 N/A N/A
SPECIFICATIONS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 19
MTSMC-LVW2 Power Draw
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
3.3 Volts
LTE 0.006 0.026 0.691 0.768 1.24
5 Volts
LTE 0.004 0.015 0.445 0.492 1.24
MTSMC-LVW2-U Power Draw
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
3.3 Volts
LTE N/A 0.049 0.766 N/A 1.72
5 Volts
LTE N/A 0.027 0.500 N/A 1.57
MTSMC-LEU1 Power Draw
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
3.3 Volts
EGSM 900Mhz 0.012 0.031 0.549 2.42 1.13
LTE 0.010 0.059 0.990 N/A N/A
5 Volts
EGSM 900Mhz 0.006 0.018 0.236 1.34 1.09
LTE 0.004 0.049 0.610 N/A N/A
SPECIFICATIONS
20 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
MTSMC-LEU1-U Power Draw
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
3.3 Volts
EGSM 900Mhz N/A 0.0561 0.780 2.75 1.65
LTE N/A 0.075 0.980 N/A N/A
5 Volts
EGSM 900Mhz N/A 0.030 0.285 1.50 1.42
LTE N/A 0.043 0.610 N/A N/A
Mounting Hardware
The board has three mounting holes at corners. Use #4 or M3 hardware for mounting the SocketModem to the
board. Refer to the Mechanical Drawings for more information.
Recommended Parts
Manufacturer Part Part Number
PEM (Penn Engineering &
Manufacturing)
Surface Mount Standoff SMTSO-M3-4ET
RAF Electronic Hardware 3/16” Hex Female Standoff 2051T-440-S-12-Zinc
RAF Electronic Hardware 4.5mm Hex Female Standoff 1251-3005-S-12-Zinc
ANTENNAS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 21
Chapter 4 – Antennas
Antenna System Cellular Devices
The antenna system is defined as the UFL connection point from the device through the cable and antenna. Device
performance depends on implementation and antenna system design. Integrating the antenna system is a critical
part of the design process; therefore, it is essential to consider it early so the performance is not compromised.
Requirements for Cellular Antennas with regard to FCC/IC Compliance
The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the
listed antenna. The antenna used must stay below the FCC/IC maximum gain.
For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was
shipping when this document was last updated.
PTCRB Requirements
There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with
similar in-band and out-of-band radiation patterns and maintain the same specifications.
Antenna Overview
For MTSMC-LAT1 models, we tested with the Laird LTE Antenna.
For MTSMC-LEU1 or MTSMC-LVW2 models, we tested with the Wieson LTE Antenna
EAD Antenna
The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer: Embedded Antenna Systems, Ltd. (EAD)
Description: Dipole Blade Antenna for LTE
MultiTech ordering information:
Model Quantity
ANLTE3-2HRA 2
ANLTE3-10HRA 10
ANLTE3-50HRA 50
ANTENNAS
22 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
LTE Antenna Specifications
Category Description
Frequency Range 698-806 MHz
824-894 MHz
880-960 MHz
1710-1880 MHz
1850-1990 MHz
1920-2170 MHz
2100-2500 MHz
2500-2690 MHz
Impedance 50 Ohms
VSWR < 2.5:1
Typical Radiated Gain Low band 0.5 dBi (698-960 MHz)
High band 2.2 dBi (1710-2700 MHz)
Radiation Omni-directional
Polarization Linear
Wieson Antenna
Devices were approved with the following antenna:
Manufacturer: Wieson
Description: LTE GY115HT467-017
Model Number: 11320Y11194A1
MultiTech Part Number: 45009890L
MultiTech ordering information:
Model Quantity
ANLTE2-1HRA 1
ANLTE2-10HRA 10
ANLTE2-50HRA 50
Antenna Specifications
Category Description
Frequency Range .069~0.96GHz, 1.71~2.17GHz, 2.3GHz~2.69GHz
Impedance 50 Ohms
VSWR VSWR should not exceed 3:1 at any point across the bands of operation
ANTENNAS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 23
Category Description
Peak Gain 3.8 dBi
Radiation Omni-directional
Polarization Linear Vertical
LTE Antenna Diversity
Antenna diversity uses two receive antennas to improve the downlink connection (cell tower to mobile). It has no
effect on the uplink (mobile to cell tower).
Antenna diversity is useful in environments where the signal arrives at the device after bouncing off or around
buildings or other objects. The bounced signal may be attenuated by going through semi-transparent (to the
signal) objects. Each signal alteration can change its magnitude, phase, orientation, or polarization. This complex
environment can exist in cities, inside buildings or in traffic. In this environment, signal paths from the cell tower
form an interference pattern of peaks and nulls. These peaks and nulls can be very close together.
Antenna diversity provides an advantage in complex environments because if one receive antenna has a poor
signal due to an interference null pattern, the other antenna is likely not in the null and has better reception. The
radio compares the reception from both receive antennas and uses the one with the strongest signal.
Important: You must deploy with two antennas, unless your carrier has authorized you to deploy with one
antenna.
Selecting Antennas
Select an antenna based on your product and application. Typically, both antennas are the same and either can be
the main receive antenna.
Placing External Antennas
Antennas are usually a quarter wavelength apart from each other. With multiband radios where the quarter
wavelengths in each band are diverse from each other, this rule may not be practical. Choose spacing based on the
band used most often or the band with connection difficulty. Some environments are harsher on particular bands.
MultiTech products have antenna connectors at the best spacing for the product size.
Placing antennas in close proximity to each other is not optimal, but you can do it if necessary. It depends on the
signal strength to and from each antenna.
If the antennas are too close together for your application, use a similar antenna on a short cable for the second
receive only antenna.
Placing GPS Antennas
GPS antennas need a clear view of the sky. Position the GPS antenna so the diversity antennas do not block its
view of the sky.
Antenna Approvals and Safety Considerations
Note the following:
Carriers conduct antenna diversity tests.
There are no EMC concerns about antenna diversity.
ANTENNAS
24 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
All antennas need to have a minimum flammability rating.
Safety requirements depend on your final product.
Unless otherwise noted, antennas certified by MultiTech are not approved for outdoor use. Do not extend
these antennas outside of any building.
Diversity and Power Draw
There are no significant power draw differences.
GPS Antenna Specifications
Manufacturer: Trimble
Description: GPS Antenna with low noise amplifier
Model Number: 66800-52
Multi-Tech Part Number: 45009665L
MultiTech Ordering Information
Model Quantity
ANGPS-1MM 1
ANGPS-10MM 10
ANGPS-50MM 50
Antenna Specifications
Category Description
Frequency Range 1575.24 MHz
Impedance 50 Ohms
VSWR 2.0:1 max
Gain 10-30 dBi
LNA Current Consumption 40 mA max
Noise Figure < 2dB
Polarization RHCP
Input voltage 3.0V M M 0.2V
OEM Integration
FCC & IC Information to Consumers
The user manual for the consumer must contain the statements required by the following FCC and IC regulations:
47 C.F.R. 15.19(a)(3), 15.21, 15.105 and RSS-Gen Issue 3, Dec 2010; 7.1.2 and 7.1.3
ANTENNAS
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 25
FCC Grant Notes
The OEM should follow all the grant notes listed below. Otherwise, further testing and device approvals may be
necessary.
FCC Definitions
Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used so that the
radiating structure(s) of the device is/are within 20 centimeters of the body of the user.
Mobile: (§2.1091) — A mobile device is defined as a transmitting device designed to be used in other than fixed
locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally
maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons.
Actual content pending Grant:This device is a mobile device with respect to RF exposure compliance. The
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all
persons, and must not be collocated or operate in conjunction with any other antenna or transmitter except in
accordance with FCC multi-transmitter product guidelines. Installers and end-users must be provided with specific
information required to satisfy RF exposure compliance for installations and final host devices. (See note under
Grant Limitations.) Compliance of this device in all final host configurations is the responsibility of the Grantee.
Note: Host design configurations constituting a device for portable use (<20 cm from human body) require
separate FCC/IC approval.
Note: Only use antennas approved respectively as listed for the unlicensed radios (Bluetooth/Wi-Fi)
Host Labeling
The following statements are required to be on the host label:
This device contains FCC ID: {Add the FCC ID of the specific device}
This device contains equipment certified under IC ID: {Add the IC ID of the specific device}
For additional labeling requirements, see the product's Labeling Requirements. For the FCC and IC IDs, see specific
certificate information in the Regulatory Statement chapter.
SAFETY INFORMATION
26 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Chapter 5 – Safety Information
Handling Precautions
To avoid damage due to the accumulation of static charge, use proper precautions when handling any cellular
device. Although input protection circuitry has been incorporated into the devices to minimize the effect of static
build-up, use proper precautions to avoid exposure to electronic discharge during handling and mounting the
device.
Power Supply Caution
CAUTION: Do not replace the power supply with one designed for another product; doing so can damage the
modem and void your warranty.
CAUTION: Pour garantir une protection continue contre les risques d'incendie, remplacez les fusibles
uniquement par des fusibles du même type et du même calibre.
Note: Serial models include power supply but USB models do not.
Radio Frequency (RF) Safety
Due to the possibility of radio frequency (RF) interference, it is important that you follow any special regulations
regarding the use of radio equipment. Follow the safety advice given below.
Operating your device close to other electronic equipment may cause interference if the equipment is
inadequately protected. Observe any warning signs and manufacturers’ recommendations.
Different industries and businesses restrict the use of cellular devices. Respect restrictions on the use of
radio equipment in fuel depots, chemical plants, or where blasting operations are in process. Follow
restrictions for any environment where you operate the device.
Do not place the antenna outdoors.
Switch OFF your wireless device when in an aircraft. Using portable electronic devices in an aircraft may
endanger aircraft operation, disrupt the cellular network, and is illegal. Failing to observe this restriction
may lead to suspension or denial of cellular services to the offender, legal action, or both.
Switch OFF your wireless device when around gasoline or diesel-fuel pumps and before filling your vehicle
with fuel.
Switch OFF your wireless device in hospitals and any other place where medical equipment may be in use.
Sécurité relative aux appareils à radiofréquence (RF)
À cause du risque d'interférences de radiofréquence (RF), il est important de respecter toutes les réglementations
spéciales relatives aux équipements radio. Suivez les conseils de sécurité ci-dessous.
Utiliser l'appareil à proximité d'autres équipements électroniques peut causer des interférences si les
équipements ne sont pas bien protégés. Respectez tous les panneaux d'avertissement et les
recommandations du fabricant.
Certains secteurs industriels et certaines entreprises limitent l'utilisation des appareils cellulaires. Respectez
ces restrictions relatives aux équipements radio dans les dépôts de carburant, dans les usines de produits
chimiques, ou dans les zones où des dynamitages sont en cours. Suivez les restrictions relatives à chaque
type d'environnement où vous utiliserez l'appareil.
Ne placez pas l'antenne en extérieur.
SAFETY INFORMATION
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 27
Éteignez votre appareil sans fil dans les avions. L'utilisation d'appareils électroniques portables en avion est
illégale: elle peut fortement perturber le fonctionnement de l'appareil et désactiver le réseau cellulaire. S'il
ne respecte pas cette consigne, le responsable peut voir son accès aux services cellulaires suspendu ou
interdit, peut être poursuivi en justice, ou les deux.
Éteignez votre appareil sans fil à proximité des pompes à essence ou de diesel avant de remplir le réservoir
de votre véhicule de carburant.
Éteignez votre appareil sans fil dans les hôpitaux ou dans toutes les zones où des appareils médicaux sont
susceptibles d'être utilisés.
Interference with Pacemakers and Other Medical Devices
Potential interference
Radio frequency energy (RF) from cellular devices can interact with some electronic devices. This is
electromagnetic interference (EMI). The FDA helped develop a detailed test method to measure EMI of implanted
cardiac pacemakers and defibrillators from cellular devices. This test method is part of the Association for the
Advancement of Medical Instrumentation (AAMI) standard. This standard allows manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from cellular device EMI.
The FDA continues to monitor cellular devices for interactions with other medical devices. If harmful interference
occurs, the FDA will assess the interference and work to resolve the problem.
Precautions for pacemaker wearers
If EMI occurs, it could affect a pacemaker in one of three ways:
Stop the pacemaker from delivering the stimulating pulses that regulate the heart's rhythm.
Cause the pacemaker to deliver the pulses irregularly.
Cause the pacemaker to ignore the heart's own rhythm and deliver pulses at a fixed rate.
Based on current research, cellular devices do not pose a significant health problem for most pacemaker wearers.
However, people with pacemakers may want to take simple precautions to be sure that their device doesn't cause
a problem.
Keep the device on the opposite side of the body from the pacemaker to add extra distance between the
pacemaker and the device.
Avoid placing a turned-on device next to the pacemaker (for example, don’t carry the device in a shirt or
jacket pocket directly over the pacemaker).
Vehicle Safety
When using your device in a vehicle:
Do not use this device while driving.
Respect national regulations on the use of cellular devices in vehicles.
If incorrectly installed in a vehicle, operating the wireless device could interfere with the vehicle’s
electronics. To avoid such problems, use qualified personnel to install the device. The installer should verify
the vehicle electronics are protected from interference.
Using an alert device to operate a vehicle’s lights or horn is not permitted on public roads.
SAFETY INFORMATION
28 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
UL evaluated this device for use in ordinary locations only. UL did NOT evaluate this device for installation in
a vehicle or other outdoor locations. UL Certification does not apply or extend to use in vehicles or outdoor
applications.
Device Maintenance
Do not attempt to disassemble the device. There are no user serviceable parts inside.
When maintaining your device:
Do not misuse the device. Follow instructions on proper operation and only use as intended. Misuse could
make the device inoperable, damage the device and/or other equipment, or harm users.
Do not apply excessive pressure or place unnecessary weight on the device. This could result in damage to
the device or harm to users.
Do not use this device in explosive or hazardous environments unless the model is specifically approved for
such use. The device may cause sparks. Sparks in explosive areas could cause explosion or fire and may
result in property damage, severe injury, and/or death.
Do not expose your device to any extreme environment where the temperature or humidity is high. Such
exposure could result in damage to the device or fire. Refer to the device specifications regarding
recommended operating temperature and humidity.
Do not expose the device to water, rain, or spilled beverages. Unless the device is IP67 rated, it is not
waterproof. Exposure to liquids could result in damage to the device.
Do not place the device alongside computer discs, credit or travel cards, or other magnetic media. The
information contained on discs or cards may be affected by the device.
Using accessories, such as antennas, that MultiTech has not authorized or that are not compliant with
MultiTech's accessory specifications may invalidate the warranty.
If the device is not working properly, contact MultiTech Technical Support.
Notice regarding Compliance with FCC, EU, and Industry Canada
Requirements for RF Exposure
The antenna intended for use with this unit meets the requirements for mobile operating configurations and for
fixed mounted operations, as defined in 2.1091 of the FCC rules for satisfying RF exposure compliance. This device
also meets the European RF exposure requirements of EN 62311. If an alternate antenna is used, consult user
documentation for required antenna specifications.
Compliance of the device with the FCC, EU and IC rules regarding RF Exposure was established and is given with
the maximum antenna gain as specified above for a minimum distance of 20 cm between the devices radiating
structures (the antenna) and the body of users. Qualification for distances closer than 20 cm (portable operation)
would require re-certification.
Wireless devices could generate radiation. Other nearby electronic devices, like microwave ovens, may also
generate additional radiation to the user causing a higher level of RF exposure.
User Responsibility
Respect all local regulations for operating your wireless device. Use the security features to block unauthorized use
and theft.
CE
REGULATORY INFORMATION
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 29
Chapter 6 – Regulatory Information
EMC, Safety, and Radio Equipment Directive (RED) Compliance
The CE mark is affixed to this product to confirm compliance with the following European Community Directives:
Council Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical
and electronic equipment;
and
Council Directive 2014/53/EU on radio equipment and telecommunications terminal equipment and the
mutual recognition of their conformity.
MultiTech declares that this device is in compliance with the essential requirements and other relevant provisions
of Directive 2014/53/EU. The declaration of conformity may be requested at https://support.multitech.com.
47 CFR Part 15 Regulation Class B Devices
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Industry Canada Class B Notice
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Reglement Canadien sur le matériel
brouilleur.
This device complies with Industry Canada license-exempt RSS standard(s). The operation is permitted for the
following two conditions:
1. the device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired operation of
the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
REGULATORY INFORMATION
30 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
1. l'appareil ne doit pas produire de brouillage, et
2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
FCC Grant Information
MTSMC-LAT1 and MTSMC-LAT1-U
FCC Part 15
FCC Identifier: RI7LE910NA
Equipment Class: Part 15 Class Computing Device Peripheral
Notes: LTE/3G/2G Module
FCC Rule Parts: 15B
Approval: Single Modular
FCC Parts 22, 24, and 27
FCC Identifier: RI7LE910NA
Equipment Class: PCS Licensed Transmitter
Notes: LTE/3G/2G Module
Approval: Single Modular
FCC Rule Parts Frequency Range
(MHz)
Output Watts Frequency
Tolerance
Emission Designators
22H 824.4-848.2 1.64059 1.0 PM 248KGXW
22H 824.4-848.2 0.42554 1.0 PM 248KG7W
24E 1850.2-1909.8 0.93325 1.0 PM 253KGXW
24E 1850.2-1909.8 0.23439 1.0 PM 246KG7W
22H 826.4-846.6 0.21727 1.0 PM 4M16G9W
22H 826.4-846.6 0.20845 1.0 PM 4M18G9W
22H 826.4-846.6 0.20989 1.0 PM 4M17G9W
24E 1852.4-1907.6 0.22336 1.0 PM 4M15G9W
24E 1852.4-1907.6 0.19231 1.0 PM 4M17G9W
24E 1852.4-1907.6 0.18155 1.0 PM 4M17G9W
27 706.5-713.5 0.18408 1.0 PM 4M52G7W
27 706.5-713.5 0.16406 1.0 PM 4M52D7W
27 709-711.0 0.18967 1.0 PM 8M98G7W
27 709-711.0 0.17458 1.0 PM 9M01D7W
22H 826.5-846.5 0.20559 1.0 PM 4M51G7W
REGULATORY INFORMATION
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 31
FCC Rule Parts Frequency Range
(MHz)
Output Watts Frequency
Tolerance
Emission Designators
22H 826.5-846.5 0.16904 1.0 PM 4M50D7W
22H 829.0-844.0 0.19409 1.0 PM 9M00G7W
22H 829.0-844.0 0.16331 1.0 PM 9M00D7W
27 1712.5-1752.5 0.17378 1.0 PM 4M51G7W
27 1712.5-1752.5 0.17906 1.0 PM 4M51D7W
27 1715.0-1750.0 0.1803 1.0 PM 9M01G7W
27 1715.0-1750.0 0.1766 1.0 PM 8M89D7W
27 1720.0-1745.0 0.18113 1.0 PM 17M9G7W
27 1720.0-1745.0 0.19454 1.0 PM 18M0D7W
24E 1852.5-1907.5 0.19815 1.0 PM 4M50G7W
24E 1852.5-1907.5 0.18793 1.0 PM 4M51D7W
24E 1855.0-1905.0 0.18155 1.0 PM 9M01G7W
24E 1855.0-1905.0 0.18323 1.0 PM 8M97D7W
24E 1860.0-1900.0 0.1803 1.0 PM 17M9G7W
24E 1860.0-1900.0 0.17579 1.0 PM 17M9D7W
Single Modular Approval. Power output listed is conducted. This device is approved for mobile and fixed use with
respect to RF exposure compliance, and may only be marketed to OEM installers. The antenna(s) used for this
transmitter, as described in this filing, must be installed to provide a separation distance of at lease 20 cm from all
persons and must not be co-located or operate in conjunction with any other antenna or transmitter, except in
accordance with FCC multi0-transmitter product procedures. Installers and end-users must be provided with
operating conditions for satisfying RF exposure compliance. Maximum permitted antenna gain/cable loss: 700
MHz: 8.74 dBi, 850MHz; 6.93 dBi, 1700MHz: 5.0 dBi, 1900Mhz: 2.51 dBi.
REGULATORY INFORMATION
32 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
MTSMC-LVW2 and MTSMC-LVW2-U
FCC Part 15
FCC Identifier: RI7LE910SV
Equipment Class: Part 15 Class Computing Device Peripheral
Notes: LTE Module
FCC Rule Parts: 15B
Approval: Single Modular
FCC Parts 27
FCC Identifier: RI7LE910SV
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: LTE Module
Approval: Single Modular
FCC Rule Parts Frequency Range
(MHz)
Output Watts Frequency
Tolerance
Emission Designators
27 779.5 - 784.5 0.19543 14.0 Hz 5M52G7D
27 779.5 - 784.5 0.20749 14.0 Hz 4M53D7D
27 782.0 - 782.0 0.19231 14.0 Hz 8M95G7D
27 782.0 - 782.0 0.17824 14.0 Hz 8M95D7D
27 1712.5-1752.5 0.22856 27.0 Hz 4M52G7D
27 1712.5-1752.5 0.21928 27.0 Hz 4M53D7D
27 1715.0-1752.5 0.22336 27.0 Hz 8M95G7D
27 1715.0-1752.5 0.19123 27.0 Hz 8M94D7D
27 1720.0-1745.0 0.21928 27.0 Hz 17M9G7D
27 1720.0-1745.0 0.20559 27.0 Hz 17M9D7D
Single Modular Approval. Power output listed is conducted. This device is approved for mobile and fixed use with
respect to RF exposure compliance, and may only be marketed to OEM installers. The antenna(s) used for this
transmitter, as described in this filing, must be installed to provide a separation distance of at least 20 cm from all
persons and must not be co-located or operate in conjunction with any other antenna or transmitter, except in
accordance with FCC multi-transmitter product procedures. Installers and end-users must be provided with
operating conditions for satisfying RF exposure compliance. Maximum permitted antenna gain/cable loss: LTE Band
4: 5.0 dBi, LTE Band 13: 9.16 dBi.
Industry Canada Certification
REGULATORY INFORMATION
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 33
MTSMC-LAT1 and MTSMC-LAT1-U
Certification Number/No. de Certification 5131A-LE910NA
Type of Radio Equipment/Genre de Matériel Advanced Wireless Services Equipment/Matériel des
services sans fil évolués (1710-1755 MHz and 2110-2155
MHz)
Cellular Mobile GSM/ Téléphone cellulaire mobile GSM
(824-849 MHZ)
Cellular Mobile New Technologies/Téléphone cellulaire
mobile - Nouvelles technologies (824-849 MHz)
PCS Mobile/Téléphone mobile SCP (1850-1910 MHz)
Mobile Broadband Service (MBS)/Matériel du service
mobile à large bande (SMLB) (698-756 and (777-787)
Modular Approval/Approbation modulaire
Model/Modèle LE910-NAG
Specification/Ca
hier des Charges
Issue/Édit
ion
From
Frequency/D
e Fréquences
To
Frequency
/Á
Fréquence
s
Emmission
Designation/Desig
nation D’émission
Minimu
m
Power
Maximum Power
RSS130 1.0 709 M 711 M 8M98G7W 189.67
mW
189.67 mW
RSS132 3.0 826.5 M 846.5 M 4M51G7W 205.59
mW
205.59 mW
RSS132 3.0 824.2 M 848.2 M 248KG7W 425.54
mW
425.54 mW
RSS133 6.0 1.85 G 1.91 G 253KGXW 933.25
mW
933.25 mW
RSS132 3.0 826.4 M 846.6 M 4M17G9W 209.89
mW
209.89 mW
RSS130 1.0 706.5 M 713.5 M 4M52D7W 164.06
mW
164.06 mW
RSS132 3.0 826.4 M 846.6 M 4M16G9W 217.27
mW
217.27 mW
RSS132 3.0 826.5 M 846.5 M 4M50D7W 169.04
mW
169.04 mW
RSS133 6.0 1.85 G 1.91 G 246KG7W 234.39
mW
234.39 mW
RSS133 6.0 1.852 G 1.908 G 4M17G9W 181.55
mW
181.55 mW
REGULATORY INFORMATION
34 SocketModem ®Cell LTE MTSMC-Lxx Device Guide
Specification/Ca
hier des Charges
Issue/Édit
ion
From
Frequency/D
e Fréquences
To
Frequency
/Á
Fréquence
s
Emmission
Designation/Desig
nation D’émission
Minimu
m
Power
Maximum Power
RSS132 3.0 829 M 844 M 9M00D7W 163.31
mW
163.31 mW
RSS139 2.0 1.713 G 1.752 G 4M51G7W 173.78
mW
173.78 mW
RSS133 6.0 1.852 G 1.908 G 4M17G9W 192.31
mW
192.31 mW
RSS139 2.0 1.72 G 1.745 G 18M0D7W 194.54
mW
194.54 mW
RSS139 2.0 1.713 G 1.752 G 4M51D7W 179.06
mW
179.06 mW
RSS133 6.0 1.852 G 1.908 G 4M50G7W 198.15
mW
198.15 mW
RSS132 3.0 829 M 844 M 9M00G7W 194.09
mW
194.09 mW
RSS132 3.0 826.4 M 846.6 M 4M18G9W 208.45
mW
208.45 mW
RSS139 2.0 1.72 G 1.745 G 17M9G7W 181.13
mW
181.13 mW
RSS133 6.0 1.86 G 1.9 G 17M9G7W 180.3
mW
180.3 mW
RSS130 1.0 709 M 711 M 9M01D7W 174.58
mW
174.58 mW
RSS139 2.0 1.715 G 1.75 G 8M89D7W 176.6
mW
176.6 mW
RSS133 6.0 1.852 G 1.908 G 4M51D7W 187.93
mW
187.93 mW
RSS133 6.0 1.852 G 1.908 G 4M15G9W 223.36
mW
223.36 mW
RSS133 6.0 1.855 G 1.905 G 9M01G7W 181.55
mW
181.55 mW
RSS139 2.0 1.715 G 1.75 G 9M01G7W 180.3
mW
180.3 mW
RSS132 3.0 824.2 M 848.2 M 248KGXW 1.641 W 1.641 W
RSS130 1.0 706.5 M 713.5 M 4M52G7W 184.08
mW
184.08 mW
REGULATORY INFORMATION
SocketModem ®Cell LTE MTSMC-Lxx Device Guide 35
Specification/Ca
hier des Charges
Issue/Édit
ion
From
Frequency/D
e Fréquences
To
Frequency
/Á
Fréquence
s
Emmission
Designation/Desig
nation D’émission
Minimu
m
Power
Maximum Power
RSS133 6.0 1.86 G 1.9 G 17M9D7W 175.79
mW
175.79 mW
RSS133 6.0 1.855 G 1.905 G 8M97D7W 183.23
mW
183.23 mW
Certification of equipment means only that the equipment has met the requirements of the above noted
specification. License applications, where applicable to use certified equipment, are acted on accordingly by the
Industry Canada issuing office and will depend on the existing radio environment, service and location of
operation. This certificate is issued on condition that the holder complies and will continue to comply with the
requirements and procedures issued by Industry Canada. The equipment for which this certificate is issued shall
not be manufactured, imported distributed, leased, offered for sale or sold unless the equipment complies with
the applicable technical specifications and procedures issued by Industry Canada.
La certification du matériel signifie seulement que le matériel a satisfait aux exigences de la norme indiquée ci-
dessus. Les demandes de licences nécessaires pour l’utilisation du matériel certifié sont traitées en conséquence
par le bureau de délivrance d’Industrie Canada et dépendent des conditions radio ambiantes, du service et de
l’emplacement d’exploitation. Le présent certificat est délivré à la condition que le titulaire satisfasse et continue
de satisfaire aux exigences et aux procédures d’Industrie Canada. Le matériel à l’égard duquel le présent certificat
est délivré ne doit pas être fabriqué, importé, distribué, loué, mis en vente ou vendu à moins d’être conforme aux
procédures et aux spécifications techniques applicable publiées par Industrie Canada.
MTSMC-LVW2 and MTSMC-LVW2-U
Certification Number/No. de Certification 5131A-LE910SV
Type of Radio Equipment/Genre de Matériel Advanced Wireless Services Equipment/Matériel des
services sans fil évolués (1710-1755 MHz and 2110-2155
MHz)
Mobile Broadband Service (MBS)/Matériel du service
mobile à large bande (SMLB) (698-756 and (777-787)
Modular Approval/Approbation modulaire
Model/Modèle LE910-SVG
Specification/Ca
hier des Charges
Issue/Édit
ion
From
Frequency/D
e Fréquences
To
Frequency
/Á
Fréquence
s
Emmission
Designation/Desig
